TAROT custom 600TVL mini HD color camera (FPV aerial camera) using 2.8MM 120 degree wide-angle lens focal length of a full glass for mini200 / 250/300 through a small machine, FPV aerial aeromodelling field, monitoring. Products are small, built-in step-down module, can be directly connected 3S11.1V use lithium polymer battery.
Wiring instructions:
Red DC12V power input connection
Black ground wire connected to the negative power supply and video
White connected AV video signal output
Working temperature: 0 ℃ ~ 45 ℃
An electronic shutter (N) 1 / 60-1 / 10000s, (P) 1 / 50-1 / 10000s
SNR: greater than 50dB
Power consumption: 40MA ± 10%
Operating voltage: DC5-15V ± 10%
Video system: NTSC / PAL
Effective pixels: PAL = 720 (H) × 576 (V) / NTSC = 720 (H) × 487 (V)
Definition: 600TV Lines (HD)
600TVL mini HD color camera
